Ultrasonic Flaw Detectors
Ultrasonic Flaw Detectors - From Easy-to-Use, Hand-held Ultrasonic Flaw Detectors to ultra high performance Phased
Array Ultrasonic Flaw Detectors for many Ultrasonic Flaw Detection Applications including crack detection, weld
inspection, defect sizing and more.
The Avenger II is rugged lightweight, hand-held ultrasonic instrument utilized
daily in the evaluation of Investment Castings, In Service Inspection, Plastics, and
Turbine blades, Tanks, Tubes and Pipes. Incorporating a palmtop design with a
light weight of 800 grams, the Avenger II allows for a grip-orientated weight
distribution to maximize ultrasonic testing efficiency.
The Raptor a very high performance Ultrasonic Flaw Detector with a Full Imaging
system built in. Low cost, High Accuracy defect mapping and recording. Ideal for
all tasks from Corrosion mapping to composite inspection. A wide range of
scanners are available to suit differing tasks. Our most popular ultrasonic flaw
detector.
The utPod Ultra-Portable Ultrasonic Flaw Detector & Thickness / Corrosion
Gauge. Can be worn on the wrist giving hands free operation, ideal for rope
access work etc.
The Curlin Air Non Contact, Air Coupled, Ultrasonic Flaw Detector & Composite
Bond Tester. The amazing penetrating power allows the inspection of
materials/structures not normally considered testable. The lack of couplant
avoids contamination of surface and allows the testing of porous materials.
The ISonic 2008 a portable high specification Ultrasonic Flaw Detector with 8
independent test channels. Inspect with up to 8 transducers simultaneously e.g.
bracelet scanners.
A-Scan, B-Scan, CB (projection C-Scan for inaccessible areas), TOFD and strip
chart presentations.
The ISonic 2009 UPA Scope is a portable high performance Ultrasonic Phased
Array Flaw Detector & Recorder with Conventional UT & TOFD Channels.
The ISonic 3505 an amazing performance (140dB dynamic range), full featured
portable flaw detector and recorder.
A-Scan, B-Scan, CB-Scan (Projection C-Scan for testing inaccessible areas), C-Scan
and TOFD. Video recording option & remote control facility.
The ISonic 3507 has all the features of the ISonic 3505 with the addition of Dual
Channels for special requirements such as thick section TOFD. Data may also be
presented in the form of strip charts.
The ISonic 16/32 AUT is a Multi Channel Ultrasonic Flaw Detector for Automatic
Ultrasonic Testing.
The ISonic PA AUT Platform for Automatic Ultrasonic Phased Array, TOFD &
Conventional Pulse Echo Inspection.
The Socomate Ultrasonic PC Cards - USPC 7100LA (formerly USPC 3100).
The benchmark in PC Based single channel pulser-receivers.
The Socomate FAAST system is a unique Phased Array System that can generate
multiple angles and multiple focal zones per pulse. Most PA units require several
pulses to generate different angles, focal zones etc., slowing down the scanning
speed. Using a patented pulser technology, the FAAST system can generate and
evaluate multiple beams simultaneously. This allows the FAAST to be used for
faster applications such as immersion scanning & on-line tube testing.
The SIUI Smartor is a combination of ultrasonic testing (UT) and ultrasonic
thickness measurement (TG). Weld simulation, One-Hand Operation, Smart Test
Wizard and compact.
The Sonotron ISonic 3510 a Very Powerful Superior Performance Extremely
Portable Smart Phased Array Ultrasonic Flaw Detector and Recorder with 2
Additional Channels for Conventional UT / TOFD.
Products & specifications subject to change without notice. E. & O.E.
Advanced NDT Limited
Unit 4, Elgar Business Centre
Moseley Road
Hallow, Worcester
WR2 6NJ, UK
TEL: 44 (0) 1905 371 460
EMAIL: sales@advanced-ndt.co.uk
Ultrasonic Flaw Detectors - From Easy-to-Use, Hand-held Ultrasonic
Flaw Detectors to ultra high performance Phased Array Ultrasonic Flaw
Detectors for many Ultrasonic Flaw Detection Applications including
crack detection, weld inspection, defect sizing and more.
The Raptor a very high performance Ultrasonic Flaw
Detector with a Full Imaging system built in. Low cost,
High Accuracy defect mapping and recording. Ideal for all
tasks from Corrosion mapping to composite inspection. A
wide range of scanners are available to suit differing
tasks. Our most popular ultrasonic flaw detector.
The utPod Ultra-Portable Ultrasonic Flaw Detector &
Thickness / Corrosion Gauge. Can be worn on the wrist
giving hands free operation, ideal for rope access work
etc.
The Curlin Air Non Contact, Air Coupled, Ultrasonic Flaw
Detector & Composite Bond Tester. The amazing
penetrating power allows the inspection of
materials/structures not normally considered testable.
The lack of couplant avoids contamination of surface and
allows the testing of porous materials.
The ISonic 2008 a portable high specification Ultrasonic
Flaw Detector with 8 independent test channels. Inspect
with up to 8 transducers simultaneously e.g. bracelet
scanners.
A-Scan, B-Scan, CB (projection C-Scan for inaccessible
areas), TOFD and strip chart presentations.
The ISonic 2009 UPA Scope is a portable high
performance Ultrasonic Phased Array Flaw Detector &
Recorder with Conventional UT & TOFD Channels.
The ISonic 3505 an amazing performance (140dB
dynamic range), full featured portable flaw detector and
recorder.
A-Scan, B-Scan, CB-Scan (Projection C-Scan for testing
inaccessible areas), C-Scan and TOFD. Video recording
option & remote control facility.
The ISonic 3507 has all the features of the ISonic 3505 with
the addition of Dual Channels for special requirements
such as thick section TOFD. Data may also be presented in
the form of strip charts.
The ISonic 16/32 AUT is a Multi Channel Ultrasonic Flaw
Detector for Automatic Ultrasonic Testing.
The ISonic PA AUT Platform for Automatic Ultrasonic
Phased Array, TOFD & Conventional Pulse Echo
Inspection.
The Socomate Ultrasonic PC Cards - USPC 7100LA
(formerly USPC 3100).
The benchmark in PC Based single channel pulser-
receivers.
The Socomate FAAST system is a unique Phased Array
System that can generate multiple angles and multiple
focal zones per pulse. Most PA units require several
pulses to generate different angles, focal zones etc.,
slowing down the scanning speed. Using a patented
pulser technology, the FAAST system can generate and
evaluate multiple beams simultaneously. This allows the
FAAST to be used for faster applications such as
immersion scanning & on-line tube testing.
Ultrasonic Flaw Detectors
The SIUI Smartor is a combination of ultrasonic testing
(UT) and ultrasonic thickness measurement (TG)
The Sonotron ISonic 3510 a Very Powerful Superior
Performance Extremely Portable Smart Phased Array
Ultrasonic Flaw Detector and Recorder with 2 Additional
Channels for Conventional UT / TOFD.
The Avenger II is rugged lightweight, hand-held
ultrasonic instrument. Incorporating a palmtop design
with a light weight of 800 grams.
The Avenger EZ a small lightweight but very robust hand-
held Ultrasonic Flaw Detector with large LCD display.
Flaw Detectors
